a=EXPBLUR(length, amount) |
Items in CAPS are 0/1 switches or switches with more options than 0/1. |
The Explode operation is another form of motion blur. The area selected will explode a set length or implode (based on the Length Setting). It is important to remember the Explode operation may require large amounts of computational time. This operation requires an Undo Buffer. If you do not have an Undo buffer allocated, WinImages F/x will automatically allocate one for you.
Trends
You will notice that all of the controls have a Trend button next to them. The trend button allows you to set that variable over a set of frames. Each frame of the animation can be thought of as a slice of time. The trends allow you to alter some, all, or none of the variables for a particular time slice. You will notice that the trend graphs have equidistantly spaced vertical lines. Each of these lines represents a frame in the animation. The number of frames can be altered using the Sequence controls... in the Timeline pull down menu. Animation lengths of 100 - 999 frames will be represented with a vertical bar being 10 frames, and animation length greater than 1000 frames will have a vertical bar for every 100 frames. Click here to view more information on Trends.
Length
The Length control allows you to set the length of the explode operation. The length can range from 0 to 200 pixels. If a negative length is specified the operation will be an Implode instead of an Explode. It is important to remember that increasing the length may also increase the amount of computational time needed to complete the effect. The length can be set using the slide gadget or by entering the appropriate value in the provided text entry region.
Amount
The Amount allows you to specify the intensity of the effect. The amount can range from 0% to 100%. A setting of 0% will result in a null operation when applied to the image. A setting of 100% will provide the maximum amount of explode or implode to the selected area. It is important to remember that increasing the amount may also increase the computational time needed to complete the effect. The amount can be altered by using the slide gadget or by entering the appropriate value in the provided text entry field.
